China Hydraulic Excavator C240 with CE

China Construction Machinery

C240 China Hydraulic Excavator - Specifications    Basic Dimensions
Operate weight 23600 kg 52029 lbs Total length of track 4256 mm 168"
Bucket capacity M3 0.92 Cabin height 3007 mm 118"
Engine model Cummins / ISUZU Upper structure width 2700 mm 106"
Engine power 113 / 125 kW 151 / 168 hp Undercarriage width 2980 mm 117"
Swing speed 10.5 rpm Overall height 3205 mm 126"
Ground pressure 45 Kpa Overall length 10004 mm 394"
Travel speed 5.5 / 3.3 km/h 3.4 / 2 mph Rear swing radius 2945 mm 116"
Arm digging force 191 kn Ground clearance 470 mm 19"
Gradeability 35° Clearance under counter weight 1075 mm 42"
Hydraulic tank capacity 230 L Track spacing 2375 mm 94"
Fuel tank capacity 410 L Track width 600 mm 24"
    Tumblers distance 3480 mm 137"
 Additional Specifications
Japanese Kawasaki main pump  Working Range
Japanese KYB valve Digging radius 10240 mm 403"
Japanese Kawasaki Swing motor Digging depth 6527 mm 257"
Japanese KYB Travel motor Digging height 9980 mm 393"
Italian valve, pilot control lever Dumping height 7170 mm 282"
Italian valve, pilot control lever Vertical wall digging depth 6140 mm 242"
  Swing radius 3404 mm 134"
  Delivery time: 20 - 30 days
FOB: Qingdao, CHINA
  Guarantee: 12 months

C240 Excavator with CE - Features & Specifications

China Hydraulic Excavator - The C240 excavators are used in earthworks, construction sites and large mining operations. This 24 ton excavator’s high durability has been achieved thanks to its enhanced boom and arm, large counterweights and reinforced chassis and platform. Its design ensures powerful digging (191 kN bucket digging force) under the most extreme conditions.

The cabin has been designed to increase leg space, visibility angles and comfort. Its adjustable seat, high sensitivity joystick and low noise environment are only some of the features which help reduce fatigue caused by long working hours and thus increase the operator's productivity. From here the operator has total control over all functions of the vehicle and is able know how the machine is performing due to its multifunctional dashboard.

1. Engine - ISUZU / Cummins

Their extremely high efficiency have made the Isuzu 6BG1TRP-02 and Cummins 6B5.9-C the chosen engines to power the C240 excavator. These low fuel consumption, high power engines combined with advanced imported hydraulic systems have made the C240 one of the most reliable excavators manufactured in China.

2. Dimensions

log loaders for sale

3. Loading

Nude packing - Roller vessel. FOB: Qingdao, Shandong Province CHINA

For a quotation on the C240 or any of our excavators please feel free to send us a message.
